WATER CONSERVATION
CleanTech® EVO Wall
The EVO Wall is a sleek, wall-mounted CleanTech® Automated Handwashing System, perfect for commercial front or back of house areas, and industrial hygiene zones. Removes over 99.9% of pathogens in 12 seconds for safety.
PRODUCT SPECIFICATIONS
Dimensions: 18.5" width x 21.25" length x 33.75" height
Water Consumption: 0.7 gallons (2.65 L) per 12-second hand wash cycle
Drain: 1 1/4” or 1 1/2” Slip Drain P-Trap included
Electrical: 6’ power cord included, 100-250 VAC NEMA 5-15p; International plugs available
Plumbing: Water supply hoses included, 1/2” MNPT H&C - ASSE 1070, Termostatic Mixing Valve, 35-100 PSI / 4 GPM minimum, 3/8” ID supply line minimum
SHIPPING
FINANCING
Additional Information
FEATURES
12–second wash and rinse cycle activates automatically via infrared photo-optical sensors
Compliance monitor automatically counts number of hand wash cycles
Designed for high–use areas
CIP friendly with NEMA 4X electronics enclosure
Compliance monitor automatically counts number of hand wash cycles
Full color display with wash cycle countdown timer and hygiene tips for employee training and education
Password protected administrative dashboard enables water temperature adjustment and other operational features
Hygiene event data breakdown by time and day; resettable counter for enhanced tracking
BENEFITS
Ensures hygiene SOP compliance
Removes 99.9% of dangerous pathogens
High throughput up to 4 employees per minute
Uses less water than manual hand washing methods
